Vapor-Fas Flexible Vapour Barrier Jacketing
Vapor-Fas 62-05 is a flexible vapour barrier jacketing material designed for use over insulation on commercial ductwork, piping and equipment. It is comprised of a 5-ply aluminium and polymer laminated film with an aggressive pressure sensitive adhesive and release liner.
The special multi-ply laminate film contains an outer protective coat that improves resistance to UV and environmental contaminants. It has extremely low permeability and has excellent resistance to puncture and tearing. Vapor-Fas 62-05 provides protection to the insulation from weather, moisture ingress and physical abuse.
Vapor-Fas 62-05 can be used over most types of thermal insulation including cellular glass, polyurethane, polyisocyanurate, polystyrene and rigid fibrous insulations. It resists mold and mildew growth on its surface and has excellent weathering properties making it ideal for both indoor and outdoor applications.
This flexible vapour barrier jacketing provides a fast, labor saving application, which can be easily applied in the field or in the shop with no special tools required. It can be used for both new systems as well as repairs on existing structures. This product should be installed by skilled professionals only.
Vapor-Fas 62-05 meets NFPA 90A and 90B 25/50 requirements for a Class 1 material and isa credible alternative to 3M Ventureclad.
Total film thickness:
0.09mm excluding adhesive and release liner.
0.12mm includes adhesive and release liner.
Service temperature (at jacketing surface): -40 °F to 250 °F (-40 °C to 121 °C)
